General Specifications
TIM
MX-6 (0.8 g)
Operating Ambient Temperature
0—40 °C
Pump
800–2800 rpm
(PWM controlled)
Current | Voltage
0.35 A | 12 V DC
Cold Plate
Copper, Micro Skived Fins
Tube Length
450 mm
Tube Diameter
Outer: 12.4 mm
Inner: 6.0 mm
Weight
2358 g
Compatibillity
Intel
LGA1851, LGA1700
AMD
AM5, AM4
Radiator
Material
Aluminium
Dimensions
458 (L) x 138 (W) x 38 (H) mm
VRM Module
VRM Fan
400–2500 rpm
(PWM-controlled)
Current | Voltage
0.05 A | 12 V DC
LEDs
12x A-RGB Gen2 LEDs
Current | Voltage
0.40 A | 5 V DC
Radiator Fan
General
3x P14 Pro A-RGB
Speed
400–2500 rpm
Airflow
110 cfm | 186 m³/h3/h
Static Pressure
5.2 mmH2O
Bearing
Fluid Dynamic Bearing
Current | Voltage
0.35 A | 12 V DC
Connector
4-Pin Fan Plug
RGB
LEDs
12x A-RGB Gen2 LEDs
Current | Voltage
0.40 A | 5 V DC
Connector
3-Pin A-RGB Plug + 3-Pin Socket
