| Mechanical |
| Dimensions |
O 110 x 184.2 mm (O 4.33 x 7.25") |
| Weight |
1.05 kg (2.32 lb) |
| Networking Interfaces |
(4) LAN 10/100/1000 RJ45 Ports
(1) WAN 10/100/1000 RJ45 Port |
| Buttons |
Reset |
| IDS/IPS Throughput |
850 Mbps |
| Processor |
Arm Cortex-A57 Quad-Core at 1.7 GHz |
| System Memory |
2 GB DDR RAM |
| On-Board Flash Storage |
16 GB |
| Maximum Power Consumption |
26W |
| Supported Voltage Range |
100 - 240VAC |
| Power Method |
AC Power Cord |
| Power Supply |
Internal AC/DC Power Adapter (24V, 0.6A, 100 - 240VAC) |
| Power Save |
Supported |
| Beamforming |
Supported |
TX Power*
2.4 GHz
5 GHz |
23 dBm
26 dBm |
| Antenna |
(1) Dual-Band, Quad-Polarity Antenna |
Antenna Gain
2.4 GHz
5 GHz |
3 dBi
4.5 dBi |
| Wi-Fi Standards |
802.11 a/b/g/n/ac/ac-wave2 |
| Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF |
| BSSID |
Up to 8 per Radio |
| Operating Temperature |
-10 to 45° C (14 to 113° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
CE, FCC, IC |
* Including antenna gain. Maximum TX power level may be limited by user's country-specific regulations.
