Cooler Specification
Socket compatibility
Intel Xeon LGA4677
Height (without fan)
165 mm
Width (without fan)
150 mm
Depth (without fan)
52 mm
Weight (without fan)
797 g
Height (with fan)
165 mm
Width (with fan)
150 mm
Depth (with fan)
111 mm
Weight (with fan)
1136 g
Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
NSPR
179
Max. TDP
see NSPR
Fan compatibility
140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25
Scope of delivery
- 2x NF-A15 PWM premium fan
- NA-YC1 4-pin PWM y-cable
- NT-H1 high-grade thermal compound (pre-applied)
- SecuFirm2™ mounting kit for LGA4677
- NM-SMT5 Torx® T30 mounting tool
Warranty
6 Years
FAN Specification
Model
2x Noctua NF-A15 HS-PWM
Bearing
SSO2
Max. rotational speed (+/- 10%)
1500 RPM
Min. rotational speed @ 20% PWM (+/-20%)
300 RPM
Max. airflow
140,2 m3/h
Max. acoustical noise
24,6 dB(A)
Input power (max.)
1,56 W
Voltage range
12 V
MTTF
> 150.000 h
